ANGEL Diesel Commercial Canopy Specification

ANGEL Diesel Engine Model YD/QC 4 EZLD
Cylinder No. 4
Bore * Stroke (mm) 105 x 118
Displacement (L) 4.087
Standby Power Output (kw) 50
Rated Speed (r/min) 1500-1800
Smooth Speed Rate (%) ≤5%
Fuel Consumption Rate（g/kW·h） ≤220
Cylinder Line Type Dry
Diesel Engine Type In-Line, Four-Stroke
Cooling Way Water-Cooled
Air Intake Type Natural aspiration
Lubricating Type Pressure, Flying Hybrid
Flywheel Cover Type SAE 3#
Flywheel Type SAE11.5″
Fan Diameter Φ450

ANGEL ALTERNATOR
Certification: ISO9001, ce
Place of Origin: Fujian, China
Brand Name: ANGEL
Rated Voltage: 400V/380V
Rated Output: 50.0 Kw / 62.5 KVA
Speed: 1500rpm/1800rpm
Frequency: 50Hz/60Hz
Power factor: 0.8 for three phase;1.0 for single phase
Materials: 100% copper wire
Insulation Class Class H
Protection Class: IP21/IP23
AVR for your options: sx460, mx321, sx440
Waveform Distortion Rate: ≤5%
Voltage Regulation: ≤1%
Color: Grey, Yellow, etc.
Certificated: CE,CCC,ISO9001

ANGEL Diesel Generators

Using the direct injection combustion chamber, easy start, low fuel consumption, better price performance.
Compact structure, Light weight, easier installation.
Strong power output, good speed-governing performance
The key spare part is same as of the high-speed vehicle engine parts, make non-road Quan chai diesel
engines for genset be good reliability
The assembly connection type is in line with SAE standard.
Mechanical speed governor of diesel engine is electronic governor. An electronic governing system ensures a
stable engine operation, make the engine speed more stable.
Application : Commercial premises (commercial Infrastructure), Farm, Mining, Factory, Construction
Building, Public works for utilities, Outdoor event, Hospital, Military, Telecommunications and Data
center etc.
Genset Frequency : 50HZ & 60HZ
Phase Numbers : 3 Phase
